There are many reasons to attend the Water & Wastewater Equipment, Treatment & Transport (WWETT) Show. The education courses, networking with other industry professionals and a concert with 25-cent tap beers all are great reasons to attend. But then there’s the exhibit hall. Products from more than 600 companies take up the entire 540,000 square feet of the Indiana Convention Center. This year exhibits are spilling out into the hallways.

You won’t want to miss this. Here’s an advance look at some of the vacuum trucks and components you will see in February.

Amthor International
The 4,000-gallon aluminum Matador vacuum tank from Amthor International comes standard with a 5/16-inch-thick side shell and floor, full head baffles and no external rings. It is available as a dumping tank with or without full-opening rear doors, code or non-code, as well as with off-road construction options for various oilfield and mining applications. Various pump models are available, as are chassis and stock tanks. 800/328-6633; www.amthorinternational.com; Booth #4331, 4332, 4333, 4335.

The commercial-duty V-117-850 vacuum reel from Coxreels is designed to extract unwanted particles and byproducts from the workplace. This direct hand-crank reel handles up to 50 feet of 1 1/2-inch standard vacuum hose with bullet cuffs. It has a solid one-piece steel U-shaped frame and open-drum design and a no-thread direct-connect port for fast and convenient vacuum hose installation. It is lightweight, compact and has CNC robotically spun and ribbed discs with rolled edges for safety, strength and durability. 800/269-7335; www.coxreels.com; Booth #6215.

Crescent Tank Mfg.
The Flat Vacuum Tank from Crescent Tank Mfg. can carry up to 10 portable toilets or anything needed for the job on the flat tank. It is made from 1/4-inch steel for integrity of the flat design. It can be custom-made for any job. Many chassis options are available. 585/657-4104; www.crescenttank.com; Booth #1102, 1103.

Fruitland Manufacturing
The Eliminator 250 package from Fruitland Manufacturing is specifically designed for the portable sanitation service industry, and includes the Fruitland RCF250 commercial and continuous duty vacuum pump, creating optimal vacuum for the portable sanitation business (180 cfm). It has a heavy-duty and integral secondary shut-off, oil-catch muffler, drive coupling, vacuum/pressure gauge and all relief and drain valves. Hydraulic or gearbox drive adapters make vacuum system hook up easy, durable and professional. The package has a compact design measuring just 26 inches wide by 23 inches high, making installation on frame space-limited portable sanitation service trucks easy. 800/663-9003; www.fruitlandmanufacturing.com; Booth #6007.

Keith Huber
The Knight PD air-mover from Keith Huber is capable of 6,100 cfm, and incorporates deep vacuum with the ability to pressure off-load. The Huber Master Control allows the operator to switch easily from wet to dry product with no downtime. Its wet/dry diverter valve filtration, deep-vacuum loading and high air conveyance are designed to help move sludges and dry product. 800/334-8237; www.keithhuber.com; Booth #4115.

Lely Tank and Waste Solutions
The 3,600-gallon septic truck from Lely Tank and Waste Solutions is built on a 56,000 GVWR Peterbilt chassis with an Allison 3000 RDS transmission. The tank is dual compartment with a 300-gallon water tank. The spring-mounted tank has top and rear manways with a 12-inch primary, 4-inch inlets and a 6-inch discharge with valves. The vacuum pump is a Masport HXL400 plug-and-play with oil catch and final filter. The systems include a jetter with 200-foot hose reel with electric return. Toolboxes are mounted on both sides, and the bumper has a receiver with trailer connections. 800/367-5359; www.lelytank.com; Booth #5316, 5317, 5319.

Logan Clutch Corporation
Self-adjusting, hydraulic or pneumatic Bell Housing PTO clutches from Logan Clutch Corporation are available for diesel and gasoline-powered waterjet blasting machines. They mount directly to a diesel or gasoline engine’s flywheel, and replace older style, mechanical lever-activated PTOs. Piston travel compensates for any disc wear, eliminating the need for mechanical linkages, levers and yokes. When pressure is removed, release springs separate the friction and steel disc pack, maintaining a running clearance when disengaged. Push-button, remote activation from inside a truck cab or control panel is possible. 800/525-8824; www.loganclutch.com; Booth #4004.

The HXL400WV vacuum pump from Masport is a 400 cfm pump capable of up to 25 inches Hg and 20 psi for continuous duty. It is water stabilized so it can achieve those performance levels, make pump startup easier in cold weather, and extend the life of the vacuum pump. It is compatible with tank sizes up to 5,000 gallons and can be PTO-, belt- or hydraulic-driven. 800/228-4510; www.masportpump.com; Booth #2401.


Mid-State Tank Co.
High-quality aluminum pressure vacuum tank trailers from Mid-State Tank have capacities up to 9,000 gallons. Tanks are constructed with internal baffles and external rings to satisfy a 14.9 psi design. They come in full frame with single-axle, tandem-axle or tri-axle suspension, depending on the capacity and design required. They are also available in stainless steel and DOT 407/ASME certified. 800/722-8384; www.midstatetank.com; Booth #6522, 6525.

Moro USA
The AC5 fan-cooled vacuum pump from Moro USA is a continuous duty pump for industrial applications. It is capable of a continuous vacuum of 22 inches Hg, with a free-flow rate of 460 cfm capable of pumping nonvolatile liquids and sludge from long distances, with a suggested tank size of 2,000 to 6,000 gallons. It has an integrated check valve, changeover valve, automatic oiling system, industrial-duty bearings, Viton seals and high flow-rate asbestos-free spark-proof vanes. It doesn’t require a liquid cooling system. Dual cooling fans keep it operating efficiently even in rigorous conditions. It includes 4-inch flange connections and is available in pre-assembled pump packages with stand, secondary and oil catch. It can be drive, gearbox, hydraulic, pulley or engine driven. 800/383-6304; www.morousa.com; Booth #3122.

National Vacuum Equipment
Challenger Series 4310 Blower Pro Paks from National Vacuum Equipment have been updated with a new enclosure design to improve the ease of maintenance while dramatically decreasing sound levels. An internal ballast silencing system coupled with a number of exhaust silencer options yields a package that meets the needs of end users. They are available in frame- or top-mount models, with multiple drive options. 800/253-5500; www.natvac.com; Booth #2201.

Pik Rite
Pik Rite offers a 4,000-gallon polished aluminum vacuum tank on a Peterbuilt chassis. The unit is equipped with a Masport HXL 400 vacuum pump driven by a hot-shift PTO. The tank has a 20-inch rear clean-out manway, a 20-inch top manway, and a mounted ladder with safety-grip tread. It has a 6-inch discharge valve with cam locks, and four 5-inch sight eyes. Body features include a 2- by 6-inch tubular rear bumper, and an LED running-light kit, right- and left-side toolboxes, low hose hooks and matching polished aluminum low hose trays that combine to make the truck operator friendly. 800/326-9763; www.pikrite.com; Booth #4217, 4218, 4220.

Oversized and extra heavy portable washrooms can be handled with ease by the Hooklift Routrux from Vacutrux. It has a 4,000-pound traveling winch to pull it on and lift up to 9,000 pounds. It has an 800-gallon two-compartment galvanized steel vacuum tank with Wally 202 hydraulic drive, and is shown mounted on 33,000 gross vehicle weight rating Hino chassis. 800/305-4305; www.vacutrux.com; Booth #6305.

Vantage Trailers
Aluminum vacuum tank trailers and truck-mount bodies from Vantage Trailers are specialized for the environmental, septic, grease, portable restroom and other liquid waste markets. Tanks are offered with a variety of options, including multi-compartments and vacuum systems. Dealers can assist with installation services as well as repair and maintenance. 800/826-8245; www.vantagetrailer.com; Booth #1011, 1055.

Wallenstein Vacuum Pumps - Elmira Machine Ind.
A larger off-load valve boosts performance on 750 Series pumps from Wallenstein Vacuum Pumps - Elmira Machine Industries. They have 422 cfm airflow at 1,200 rpm and vacuum up to 28 inches Hg. Cooling options include air cooling (fan), liquid cooling (jacketed housing) or dual cooling, where air injection is combined with liquid cooling. Lubrication options include a shaft-driven oil pump or an automatic air pressure system that force lubricates with no moving parts. They have extra thick and wide vanes for longer service life and lower maintenance cost. A standard flush port allows routine internal cleaning. A quick-access endplate allows easy internal inspection with no bearings to pull. 800/801-6663; www.wallenstein.com; Booth #5367.
