Vacuum Pumps
Fruitland Manufacturing ELIM G-172
The ELIM G-172 gas engine-driven system from Fruitland Manufacturing is the most compact option in the Eliminator slide-in engine-driven line. It is suitable for portable restroom and septic vacuum truck applications, especially where space and efficiency are concerns. This package comes with a 14 hp Briggs and Stratton Vanguard engine, a 127 cfm free airflow Fruitland RCF172 vacuum pump, a standard bolt-in truck mount, and is available in left-hand or right-hand orientation. Packages are also available with various pump models and types and in many different configurations.
800-663-9003; www.fruitlandmanufacturing.com
National Vacuum Equipment B250 Max Pak
The National Vacuum Equipment B250 Max Pak is designed for the portable restroom market, using a hybrid tri-lobe blower with an integral four-way motor for vacuum/pressure use and inlet filter to provide protection. It is oil-free, and its airflow is 270 cfm. It is capable of running continuously at 15 inches Hg. It comes ready to mount and includes an exhaust silencer. The 1-to-1.5 ratio gearbox makes it easy to provide optimum revolutions per minute to the blower, while keeping truck revolutions per minute in check. While designed to fit on a Ford F-550 and Ram 5500, it can mount on any truck with ample ground clearance. It is also available in hydraulic drive to accommodate four-wheel-drive.
800-253-5500; www.natvac.com
Wallenstein Vacuum Model 151
The Model 151 from Wallenstein Vacuum can be used with portable sanitation tanks and slide-in units, and at campgrounds and marinas that require a compact package. It offers 80 cfm at 15 inches Hg, with a 2-inch vacuum/pressure valve, swivel elbows for easy hookup, air pressure or mechanical lubrication, and clockwise or counterclockwise operation. It can be direct-, hydraulic-, pulley- or clutch-driven.
800-801-6663; www.wallenstein.com
Westmoor Conde PowerPaks
Conde PowerPak units from Westmoor are suitable for slide-in tank sizes from 50 to 2,000 gallons. They are compact and available in either belt- or direct-drive configurations. Direct-drive units incorporate a centrifugal clutch that allows throttling down the engine and disengaging the vacuum pump. Throttle up and the pump is in action. Specify either vacuum and pressure, or vacuum-only pump choice. Diesel-powered units are also available for applications where non-sparking engines are required.
800-367-0972; www.westmoorltd.com
Vacuum Hoses
Kuriyama of America King Bee KBEE Series
King Bee KBEE Series polyethylene liquid suction hose from Kuriyama of America provides flexibility for maneuvering in tight areas such as portable restrooms. The hose remains flexible in subzero temperatures, is crush resistant and will not kink. The easy-slide helix protects the hose tube from cover wear and moves easily over rough surfaces. Over-molded cuffs help prevent leaking. It is available in 2- and 3-inch I.D. sizes in multiple lengths. The 3-inch I.D. hose is also available as a 3-foot hose guard.
847-755-0360; www.kuriyama.com
Hose Reels
Hannay Reels Heavy-Duty 1500 Series
The Heavy-Duty 1500 Series from Hannay Reels is designed to provide durable, reliable pressure washing for portable restroom and other pumper and cleaner applications. With 3/16-inch-thick discs, a reinforced frame and an 8-inch-diameter steel 14-gauge drum, the reel counters high-pressure hose expansion concerns, provides stability and accommodates hoses with a higher bend radius. Single 3/8- through 5/8-inch I.D. hose and pressures up to 3,000 psi are supported, with optional pressures of 5,000 or 10,000 psi available upon request. With either a manual direct-crank rewind or a chain-and-sprocket drive powered by an electric, hydraulic or air motor, the reels offer simple, swift hose deployment and retraction, while keeping lengthy hose organized, according to the maker.
877-467-3357; www.hannay.com
